Handheld Drone Locator BT2515
Handheld Drone Locator BT2515
Handheld Drone Locator BT2515
Handheld Drone Locator BT2515
Handheld Drone Locator BT2515
Handheld Drone Locator BT2515
Handheld Drone Locator BT2515
Handheld Drone Locator BT2515
Handheld Drone Locator BT2515
Handheld Drone Locator BT2515
Handheld Drone Locator BT2515
Handheld Drone Locator BT2515
The handheld drone detector is mainly used to enhance public security authorities' capability in maintaining citywide political and social stability, preventing, stopping, and investigating illegal activities, and deterring behaviors that endanger public order. It actively promotes the application of information technology and big data in public security, putting the strategy of strengthening law enforcement through science and technology into practice. This device can detect drone activities within its coverage area, providing early warning and predictive assessment to assist in improving the efficiency of crime prevention and enforcement.
This handheld drone detector with a built-in database of mainstream commercial drone models, enabling independent operation. It is also equipped with Bluetooth and cellular wireless data access functions, allowing for wireless transmission of relevant alarm data and log information via Bluetooth, as well as online updates of the drone model database.

Quantity:
库存： 0
Inquire
Add to Basket

The handheld drone locator BT2515 enables drone detection, identification, and tracking through the adoption of radio spectrum analysis, Drone ID and Remote ID, thereby achieving UAV detection and early warning. It also supports multi-target positioning and trajectory tracking.


Equipment List:

No.

Item

Qty

Unit

1

Main device

1

PC

2

Charger

1

PC

3

Type C charging cable

1

PC

4

Power Bank

1

PC

5

Antenna

2

PC


1） Passive Detection: Operates only by passive reception without transmitting any electromagnetic signals; detects drone model and aircraft serial number.

2） Accurate Identification: Capable of accurately distinguishing between drones of the same brand, model, and frequency band.

3） Precise Positioning : A single device can indicate the target position of a detected drone.

4） Whitelist/Blacklist: One-click whitelist marking; drones added to the whitelist will not trigger alarms.

5） Model Support: Supports mainstream DJI drone models and RID-enabled drones.

6） Trajectory Tracking: Multi-target trajectory tracking capability; when multiple drones are detected simultaneously, their flight paths are displayed in different colors .

7） Intrusion alarm: When an intrusion is detected, the device issues audible, visual, and vibration alarms.

8） Pilot Positioning: Accurately locates the pilot (i.e., remote controller) and indicates the corresponding direction.

9） Multi-Target Positioning: Supports simultaneous accurate detection, positioning, and trajectory tracking of ≥10 drones.

10） RID Drone Detection: When drones with RID broadcast signals are present, the device marks them with a specific RID icon.

11） Data Export: Allows export of detection and decoded data.

12） Networking: Can connect to a back-end platform, supporting reporting of detection and early warning data, as well as whitelist configuration issued by the platform.

13） Online Upgrades: Supports cloud-based updates of the drone model database and software versions.


Detection Frequency Band

100MHz～6200MHz

Detection Radius

    1.5~2 km (urban environment)

  2~3 km (open environment)

Response Time

Respond time<6s

Detection Capacity

≥10 drones（Simultaneously）

Endurance

3~4h

Screen Size

6-inch FHD+（1080X2160）

Operating Temperature

-25~40℃

Storage Temperature

-40°C to +70°C

Operating System

Android

Networking

Sim card/Wi Fi

Device Weight

≤650g

Dimensions

177.5mmX85mmX34mm

Antenna Size

2 receiving antenna: 19mm (Φ) 165mm（L)

Carrying Method

Handheld/Strap

IP rating

IP67

Cooling Method

Automatic fan cooling
