Handheld Drone Detector BT2404
Handheld Drone Detector BT2404
Handheld Drone Detector BT2404
Handheld Drone Detector BT2404
Handheld Drone Detector BT2404
Handheld Drone Detector BT2404
Handheld Drone Detector BT2404
Handheld Drone Detector BT2404
Handheld Drone Detector BT2404
Handheld Drone Detector BT2404
The handheld drone detector adopts low power consumption design and highly integrated design, and can detect mainstream DJI, Autel and other rotary wing drones that use OFDM high-definition image transmission, WIFI drones, DIY drones, and FPV drones. The device has the characteristics of high detection sensitivity, long detection distance, fast response speed, low false alarm rate, and easy use.
Quantity:
库存: 0
Inquire
Add to Basket

Main functions and features
Drone detection: It can identify rotary-wing drones with OFDM high-definition image transmission such as DJI and Autel; can identify drones based on WIFI protocol; can identify 1.2G and 5G image transmission drones.
Sound and light alarm: earphone sound alarm, external sound and light alarm.
Log record: has alarm log record, and can export alarm log through USB interface.
Earphone function: has the function of obtaining alarm sound through earphone.
Firmware upgrade function: firmware upgrade through USB interface.
Multi-language switching: supports Chinese, English, and Russian.
Working status display: language, power, volume.

Technical Specification

Receiving frequency band: 800-1500MHz/2400-2485MHz/5150-5950MHz
Identification type: OFDM high-definition image transmission signal, DIY fixed-wing, FPV drones
Detection distance: ≥1km
Detection alarm method: headphones, sound and light
Log record: support no less than 500 alarm records
Upgrade and data export interface: micro-USB
Power supply: removable lithium battery (type-c charging)
Battery life: ≥4 hours (single battery)
Size: 100mm×50mm×32mm (host does not include antenna)
Weight: 200g

Operating frequency800~1500MHz
2400~2485MHz
5725~5850MHz
Identification typeOFDM high-definition image transmission signal, DIY fixed-wing, FPV drones
Detection range≥1Km(test results vary depending on model and electromagnetic environment)
Detection modePassive detection
Power supplyExternal lithium battery,3.7V
Operating temperature-20ºC~+55ºC
Time displayyear/month/day, hour/minute/second display supports the power-off storage time
Log exportWhen exporting logs, information such as the drone type, frequency, field intensity, and discovery time is displayed
Product weight<200g(Battery included, no antenna included)
Maximum endurance≥4h(Detection mode in standby state)
Product dimensions110mm*56mm*35mm±2mm(No Antenna)L*W*H
